Replacing the Low Beam
Headlamp Bulb:
1. Remove the headlamp assembly.
2. Remove the cover.
3. Turn the bulb holder
counterclockwise and remove it.
4. Remove the bulb from the
headlamp assembly.
Replacing the Side Lamp Bulb:
1. Remove the headlamp assembly.
2. Remove the service cap.
3. Remove the bulb holder.
4. Remove the bulb from the
headlamp assembly.
Install the new bulbs in reverse order.
Replacing the Fog Lamp Bulbs (If Equipped)
Note: You cannot separate the fog
lamp bulb from the bulb holder.
1. Remove the fog lamp cover
2. Remove the 2 screws.
3. Remove the lamp.
298 Maintenance
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
