UNDER HOOD OVERVIEW
3.5L V6 engine shown, 3.7L V6 engine similar
A. Engine coolant reservoir
B. Power steering fluid reservoir
C. Engine oil filler cap
D. Engine oil dipstick
E. Brake fluid reservoir
F. Battery
G. Power distribution box
H. Air filter assembly
I. Windshield washer fluid reservoir
BA C D E F G
I H
272 Maintenance
2014 Edge (edg)
Owners Guide gf, 2nd Printing, March 2014
USA (fus)
