Occupant
Passenger airbag
status indicator
Passenger airbag
Empty
OFF: Lit
Disabled
ON: Unlit
Child
OFF: Lit
Disabled
ON: Unlit
Adult
OFF: Unlit
Enabled
ON: Lit
Note: When the passenger airbag status indicator OFF lamp is
illuminated, the passenger side airbag (seat mounted) may be disabled
to avoid the risk of airbag deployment injuries.
After all occupants have adjusted their seats and put on safety belts, it is
very important that they continue to sit properly. A properly seated
occupant sits upright, leaning against the seatback, and centered on the
seat cushion, with their feet comfortably extended on the floor. Sitting
improperly can increase the chance of injury in a crash event. For
example, if an occupant slouches, lies down, turns sideways, sits forward,
leans forward or sideways, or puts one or both feet up, the chance of
injury during a crash is greatly increased.
If you think that the state of the passenger airbag status indicator lamp
is incorrect, check for the following:
• Objects lodged underneath the seat.
• Objects between the seat cushion and the center console.
• Objects hanging off the seatback.
• Objects stowed in the seatback map pocket.
• Objects placed on the occupant’s lap.
• Cargo interference with the seat.
• Other passengers pushing or pulling on the seat.
• Rear passenger feet and knees resting or pushing on the seat.
The conditions listed above may cause the weight of a properly seated
occupant to be incorrectly interpreted by the front passenger sensing
system. The person in the front passenger seat may appear heavier or
lighter due to the conditions described in the previous list.
50 Supplementary Restraints System
2014 Edge (edg)
Owners Guide gf, 2nd Printing, March 2014
USA (fus)
