Ford 2014 FUSION User Manual

Protected componentsFuse amp ratingFuse or relay number
Lighting (ambient, glove box, vanity, dome,
trunk)
10A
1
1
Memory seats, Lumbar, Power mirror
7.5A
1
2
Driver door unlock
20A
1
3
Not used (spare)
5A
1
4
Subwoofer amplifier
20A
1
5
Not used (spare)
10A
2
6
Not used (spare)
10A
2
7
Not used (spare)
10A
2
8
Not used (spare)
10A
2
9
Keypad
5A
2
10
Not used
5A
2
11
Climate control, Gear shift
7.5A
2
12
Steering wheel column, Cluster, Datalink
logic
7.5A
2
13
Not used
10A
2
14
Datalink/Gateway module
10A
2
15
Not used (spare)
15A
1
16
Not used (spare)
5A
2
17
Ignition, Push button stop/start
5A
2
18
Passenger airbag disabled indicator,
Transmission range
5A
2
19
Not used (spare)
5A
2
20
Humidity and in–car temperature
5A
2
21
233
Fusion (CC7) , enUSA
