Protected componentsFuse amp ratingFuse or relay number

Starter solenoid

30A

Not used (spare)

30A

M-type fuse

J-type fuse

Passenger Compartment Fuse

Panel

The fuse panel is located under the

instrument panel to the left of the steering

column.

Note: It may be easier to access the fuse

panel if you remove the finish trim piece.

E145984

232

Fusion (CC7) , enUSA

Fuses
