five pAssenger second-row
seAt versAtility
Fold seats in half, prop them up or remove them
entirely. Here's how to do it:
Fold One or Both Rear Seats
1. Make sure the head restraints are
in their lowest position.
2. Pull the strap on the side of the seatback.
3. Fold the seatback forward.
4. The seat folds flat.
To Prop One or Both Seats
5. Pull the strap on the rear of the seatback.
6. Push down on the yellow lever and then
push the folded seat up and forward.
7. Li the support rod.
8. Connect the support rod to the seat frame
to prevent the seat from falling backward.
CONVENIENCE
6
7
1
3
2
8
4
5
Front
Rear
14
