Ford 2016 Fusion User Manual

Protected componentsFuse amp ratingFuse or relay number
Lighting (ambient, glove box, vanity, dome,
trunk).
10A
1
1
Memory seats, lumbar, power mirror.
7.5A
1
2
Driver door unlock.
20A
1
3
Not used (spare).
5A
1
4
Subwoofer amplifier.
20A
1
5
Heated seat relay coil.
10A
2
6
Not used (spare).
10A
2
7
Not used (spare).
10A
2
8
Not used (spare).
10A
2
9
Keypad.
5A
2
10
Power decklid module.
Cellphone passport module.
Not used (spare).
5A
2
11
Climate control.
7.5A
2
12
Gear shift
Steering wheel column lock.
7.5A
2
13
Cluster.
Datelink logic.
Battery electronic control module.
10A
2
14
Datalink gateway module.
10A
2
15
Child lock.
15A
1
16
Decklid-liftglass release.
Tracking and blocking.
5A
2
17
Ignition.
5A
2
18
Push button stop start switch.
Passenger airbag disabled indicator.
7.5A
2
19
244
Fusion/Mondeo (CC7) Canada/United States of America, enUSA, First Printing
Fuses
