Protected componentsFuse amp ratingFuse or relay number
Transmission range.
Adaptive headlamp.
7.5A
2
20
Humidity and in–car temperature sensor.
5A
2
21
Occupant classification sensor.
5A
2
22
Delayed accessory (power inverter logic,
moonroof logic).
10A
1
23
Central lock unlock.
20A
1
24
Driver door (window, mirror).
30A
1
25
Front passenger door (window, mirror).
30A
1
26
Moonroof.
30A
1
27
Amplifier.
20A
1
28
Rear driver side door (window).
30A
1
29
Rear passenger side door (window).
30A
1
30
Not used (spare).
15A
1
31
Global positioning system.
10A
1
32
Display.
Voice control.
Adaptive cruise control.
Radio frequency receiver.
Radio.
20A
1
33
Active noise control.
CD changer.
Run-start bus (fuse 19, 20, 21, 22, 35, 36,
37, circuit breaker).
30A
1
34
Restraints control module.
5A
1
35
Auto-dimming rear view mirror.
15A
1
36
Continuous control damping suspension.
Rear heated seats.
245
Fusion/Mondeo (CC7) Canada/United States of America, enUSA, First Printing
Fuses
To Next Page
