Protected componentsFuse amp ratingFuse or relay number
Powertrain control module power.
20A
1
1
Engine emissions (MIL).
20A
1
2
A/C clutch control relay coil.
20A
1
3
VACC.
Active grill shutters.
Ignition coils.
20A
1
4
Not used.—5
Not used.—6
Not used.—7
Not used.—8
Not used.—9
Heated mirrors.
15A
1
10
Right hand side electronic cooling fan 3
relay.
—11
Heated rear window.
40A
2
12
Not used.—13
Powertrain control module relay.—14
Horn relay power.
20A
1
15
A/C clutch relay power.
10A
1
16
Rear heated window and heated mirrors
relay.
—17
Rear blower motor relay.—18
Not used.—19
Left hand side cooling fan relay.—20
Cooling fans series/parallel relay.—21
Electronic fan relay 2.
25A
2
22
263
Explorer (TUB) Canada/United States of America, enUSA, Edition date: 03/2016, First Printing
Fuses
