Protected componentsFuse amp ratingFuse or relay number
Trailer tow brake controller.
30A
3
46
Not used.—47
Body control module RP1 bus.
50A
3
48
Not used.—49
Body control module RP2 bus.
50A
3
50
Electronic fan relay 3.
50A
3
51
Anti-lock brake system pump.
60A
3
52
Not used.—53
Not used.—54
Not used.—55
Power inverter.
40A
2
56
Not used.—57
Not used.—58
Not used.—59
Power point (front console bin).
20A
2
60
Not used.—61
Power point (instrument panel).
20A
2
62
Fuel pump.
30A
2
63
Not used.—64
Power point (2nd row) (without USB
charger).
20A
2
65
Not used.—66
Power point (cargo area).
20A
2
67
Not used.—68
Power liftgate.
30A
2
69
265
Explorer (TUB) Canada/United States of America, enUSA, Edition date: 03/2016, First Printing
Fuses
