Protected componentsFuse amp ratingFuse or relay number
Panoramic moonroof.
30A
3
1
Starter relay.-2
Rain sensor.
15A
1
3
Blower motor relay.—4
Power point 3 - Back of console.
20A
3
5
Not used.—6
Powertrain control module - vehicle power
1.
20A
1
7
Powertrain control module power.
Powertrain control module - vehicle power
2.
20A
1
8
Emission components.
Powertrain control module relay.—9
Power point 1 - driver front.
20A
3
10
Powertrain control module - vehicle power
4.
15A
2
11
Ignition coils.
Powertrain control module - vehicle power
3.
15A
2
12
Non-emission components.
Not used.
10A
2
13
Not used.
10A
2
14
Run-start relay.—15
Power point 2 - console.
20A
3
16
Not used.—17
Not used.—18
Run-start electronic power assist steering.
10A
1
19
Adaptive cruise control.
10A
1
20
246
Fusion (CC7) Canada/United States of America, enUSA, First Printing
