ENGINE SPECIFICATIONS - 1.5L ECOBOOST™

1.5L EcoBoost engineEngine

92Cubic inches

1-3-4-2Firing order

10.0:1Compression ratio

0.025-0.029 in. (0.65-0.75 mm)Spark plug gap

Coil on plugIgnition system

Drivebelt Routing

E167586

ENGINE SPECIFICATIONS - 2.0L ECOBOOST™

2.0L EcoBoost engineEngine

122Cubic inches

1-3-4-2Firing order

9.3:1Compression ratio

0.027-0.031 in. (0.70-0.80 mm)Spark plug gap

Coil on plugIgnition system

321

Fusion (CC7) Canada/United States of America, enUSA, First Printing
