ENGINE SPECIFICATIONS - 2.7L ECOBOOST™

SpecificationMeasurement

164Cubic inches

1-4-2-5-3-6Firing order

Coil in plugIgnition system

10.0:1Compression ratio

0.028–0.031 in (0.7–0.8 mm)Spark plug gap

Drivebelt Routing

E176088

MOTORCRAFT PARTS - 1.5L ECOBOOST™

Motorcraft Part numberComponent

FA-1912Air filter element

FL-910SOil filter

BXT-90T5-500Battery

BXT-90T5-590

BAGM-48H6-760

SP-539Spark plugs

FP-71Cabin air filter

WW-2601 (driver side)Windshield wiper blade

323

Fusion (CC7) Canada/United States of America, enUSA, First Printing
