Ford 2017 FUSION User Manual

Protected componentsFuse amp ratingFuse or relay number
Climate control.
7.5A
2
12
Gear shift
Steering wheel column lock.
7.5A
2
13
Cluster.
Datalink logic.
Extended power module.
10A
2
14
Datalink gateway module.
10A
2
15
Child lock.
15A
1
16
Decklid-liftglass release.
Not used (spare).
5A
2
17
Push button stop start switch.
5A
2
18
Extended power module.
7.5A
2
19
Adaptive headlamp.
7.5A
2
20
Humidity and in–car temperature sensor.
5A
2
21
Not Used (spare).
5A
2
22
Delayed accessory (power inverter logic,
moonroof logic, driver master switch).
10A
1
23
Central lock unlock.
20A
1
24
Driver door (window, mirror).
30A
1
25
Front passenger door (window, mirror).
30A
1
26
Moonroof.
30A
1
27
Amplifier.
20A
1
28
Rear driver side door (window).
30A
1
29
Rear passenger side door (window).
30A
1
30
Not used (spare).
15A
1
31
253
Fusion (CC7) Canada/United States of America, enUSA, First Printing
Fuses
