Fuse Types

E207206

Fuse TypeCallout

Micro 2A

Micro 3B

MaxiC

MiniD

M CaseE

J CaseF

J Case Low ProfileG

255

Fusion (CC7) Canada/United States of America, enUSA, First Printing
