Protected ComponentRatingItem
Upfitter relay 1 (cutaway).40 A47
Not used (spare) (stripped
chassis).
Not used.—48
Pump electronics module.30 A49
Fuel injectors.15 A50
Power point 1.20 A51
Power at all times (PAAT)
Aux AC prep on B-pillar
vehicle connector
(cutaway).
50 A52
Not used (spare) (stripped
chassis).
Trailer tow park lamps.30 A53
R/S feed on instrument
panel connector.
40 A54
Upfitter 3 relay (cutaway).20 A55
Not used (spare) (stripped
chassis).
Power point 2 prep B-pillar
connector.
20 A56
USB smart charger.5 A58
Park lamps 1 (special order
vehicle).
10 A59
Not used.—60
Not used.—61
Not used.—62
Not used.—63
Not used.—64
Not used.—65
Not used.—66
Not used.—67
155
2023 E-Series (TE4) Canada/United States of America, enUSA, Edition date: 202111, First-Printing
Fuses
