Ford 2023 E Series User Manual

Protected ComponentRatingItem
Not used (spare).5 A9
Not used.—10
Not used.—11
Smart datalink connector.7.5 A12
Cluster.7.5 A13
Steering column control
module.
Not used (spare).15 A14
Not used (spare).15 A15
Not used.—16
Not used.7.5 A17
R/S feed for Front blend
actuator/climate mode
switch (cutaway).
7.5 A18
R/S feed to strip chassis
connector (stripped
chassis).
Radio transceiver module
and telematics control unit.
5 A19
Telematics control unit.
Ignition switch.5 A20
Not used.5 A21
Body builder B-pillar
connector (cutaway).
5 A22
Not used (stripped chassis).5 A
Not used (spare).30 A23
Not used (spare).30 A24
Not used (spare).20 A25
Not used (spare).30 A26
Not used (spare).30 A27
Not used (spare).30 A28
159
2023 E-Series (TE4) Canada/United States of America, enUSA, Edition date: 202111, First-Printing
