Ford 2023 E Series User Manual

Fuse
Amp
Rating
Wire
Color
Circuit
Number
Switch
40AYellowCAC05AUX 1
40AGreen
with
Brown
Trace
CAC06AUX 2
20AViolet
with
Green
Trace
CAC07AUX 3
20ABrownCAC08AUX 4
Learn more about auxiliary switches by
visiting
https://www.fleet.ford.com/truckbbas/.
Upfitter Interface Module (If Equipped)
The Upfitter Interface Module (UIM) is an
electronic control module that operates
equipment (such as lift buckets, cranes,
motors, salt spreaders and snow plows)
with external relays.
If you replace the module, it will require
additional programming by the upfitter.
Obtain this data directly from the upfitter
company. The upfitter contact information
is in the vehicle door opening.
For more information on the Upfitter
Interface Module and the auxiliary
switches, contact your upfitter.
