Note: Do not tighten the tether strap
enough to lift the child restraint off the
vehicle seat cushion when the child is
seated in it. Keep the tether strap just snug
without lifting the front of the child restraint.
Keeping the child restraint just touching the
vehicle seat gives the best protection in a
severe crash.
Perform the following steps to install a
child restraint with tether anchors:
3. Clip the tether strap hook to the seat
pedestal at the location shown. If the
tether strap is clipped incorrectly, the
child restraint may not be retained
properly in the event of a crash.
4. Adjust the front passenger seat to the
full rearward position.
5. Tighten the child restraint tether strap
according to the manufacturer’s
instructions.
If you do not properly anchor the child
restraint, the risk of a child being injured in
a crash greatly increases.
25
2023 E-Series (TE4) Canada/United States of America, enUSA, Edition date: 202111, First-Printing
Child Safety
