Ford C-MAX HYBRID 2015 User Manual

Protected componentsFuse amp ratingFuse or relay number
Fuel pump supply.20AF56
Not used.—F57
Not used (spare).5AF58
Passive anti-theft system.5AF59
Interior light.10AF60
Driver door switch pack.
Glove box illumination.
Overhead console switch bank.
Cigar lighter.20AF61
Second row power point.
Autowiper module.5AF62
Autodimming rear view mirror.
Not used (spare).10AF63
Not used.—F64
Liftgate release.10AF65
Driver door unlock supply.20AF66
Cell phone passport (C-MAX Energi).7.5AF67
Multi-function display.
GPS module.
Sync.
Not used (spare).15AF68
Instrument cluster.5AF69
Central lock and unlock supply.20AF70
Heating control head (manual air condi-
tioner).
7.5AF71
Climate control module.
Steering wheel module.7.5AF72
Data link connector.7.5AF73
OBD II supply.
Headlamp supply.15AF74
Fog lamp supply.15AF75
204
C-MAX (CCG) Mexico/United States of America/Canada, enUSA, CPE Review
Fuses
