MEDIA HUB (If Equipped)

The media hub is located in the center

console and has the following features:

C

B

A

E142605

A/V inputsA

SD card slotB

USB portsC

See MyFord Touch™ (page 327).

287

C-MAX (CCG) Mexico/United States of America/Canada, enUSA, CPE Review
