Fuse or relay

number

Fuse amp

rating

Protected components

83 — Not used

84 20A* TT park lamps

85 — Not used

86 7.5A* PCM keep-alive power, PCM

relay, Canister vent solenoid

87 5A* Run/start relay coil

88 — Run/start relay

89 5A* Front blower relay coil, Electrical

Power Assist Steering (EPAS)

module

90 10A* PCM, TCM, ECM (2.0L engine)

91 10A* ACC

92 10A* ABS module, Plant EVAC and fill

93 5A* Rear blower motor, Rear

defroster, TT battery charge

relays

94 30A** Passenger compartment fuse

panel run/start

95 — Not used

96 — Not used

97 — Not used

98 — A/C clutch relay

*Mini Fuses **Cartridge Fuses

Fuses 327

2013 Explorer (exp)

Owners Guide gf, 4th Printing, November 2012

USA (fus)
