Ford EXPLORER 2013 - Engine Drivebelt Routing

Engine Drivebelt Routing
3.5L / 3.5L V6 EcoBoost engines
2.0L EcoBoost engine (if equipped with drivebelt routing 1)
2.0L EcoBoost engine (if equipped with drivebelt routing 2)
A. Long drivebelt on the first pulley groove closer to the engine
B. Short drivebelt on the second pulley groove farther from the engine
A
B
Capacities and Specifications 405
2013 Explorer (exp)
Owners Guide gf, 4th Printing, November 2012
USA (fus)
