Item Capacity
Ford Part Name or
equivalent
Ford Part Number / Ford
Specification
A/C Refrigerant and
Oil Capacity
2.0L & 3.5L GTDI
47 oz (1.39L).
3.5L TiVCT
41 oz (1.21L).
Motorcraft R134A
Refrigerant
YN-19 (US),
CYN-16-R (Canada)
WSH-M17B19-A
A/C Refrigerant
Compressor Oil
6
2.0L & 3.5L GTDI
7.2 oz (215 mL)
3.5L TiVCT
9.2 oz (275 mL)
Motorcraft PAG
Refrigerant
Compressor Oil
YN-12-D
WSH-M1C231-B.
1
Use only Motorcraft DOT 4 LV High Performance Brake Fluid or equivalent meeting WSS-M6C65-A2
and ISO 4925 Class 6. Use of any fluid other than the recommended fluid may cause brake system
damage.
2
Your engine has been designed to use engine oil that meets Ford specification. It is also acceptable to
use an engine oil of recommended viscosity grade that displays the API Certification Mark for gasoline
engines.
3
Add the coolant type originally equipped in your vehicle.
4
Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and if
equipped with an in-tank cooler. The amount of transmission fluid and fluid level should be checked
by a qualified technician.
5
Use of a dual usage fluid in an automatic transmission requiring MERCON® LV may cause
transmission damage. Use of any fluid other than the recommended fluid may cause transmission
damage. Refer to scheduled maintenance information to determine the correct service interval.
6
Warning: The A/C refrigerant system contains refrigerant R134A under high pressure. Opening the
A/C refrigerant system can cause personal injury. A/C refrigerant system is to be serviced only by
qualified personnel.
408 Capacities and Specifications
2013 Explorer (exp)
Owners Guide gf, 4th Printing, November 2012
USA (fus)
