Ford FD4000E - Assembly; Unpacking; Packing List

9
ASSEMBLY
Description Qty
Wheel
Axle
2
Supporting Leg
2
Hair pin
2
Hub Cap
Screw, Self-Tapping
2
2
Unpacking
1. Place box on a level surface.
2. Remove all items from box except the generator. Make sure all items listed on the packing list are included and not
damaged.
3. Cut down the sides of the box being careful to avoid hitting the generator.
4. Leave generator on box to install wheel assembly.
Packing List
Check all loose parts to the following list. Contact your dealer if any loose parts are not included.
Washer
2
M6 x 12mm Hex Bolts for Foot
4
+ + +
+
(
)
+
M8 x 45mm Hex Bolts for Handle
M8 Flanged Nuts for Handle
2
2
8 - 10
10 - 12
Description Qty
Generator
1
Quick Start Guide
1
Toolkit
Phillips screwdriver
10mm Combination Wrench
1
Funnel
1
Handles
2
3
+
Outlets
14 - 17
M6 Flanged Nuts
4
Spring card
Plastic card for Handle
2
2
2
1
1
1
12mm Combination Wrench
17mm Combination Wrench
