Ford Flex 2016 - Fuses; Fuse Specification Chart

FUSE SPECIFICATION CHART
Power Distribution Box
WARNINGS
Always disconnect the battery before
servicing high-current fuses.
To reduce risk of electrical shock,
always replace the cover to the
power distribution box before
reconnecting the battery or refilling fluid
reservoirs.
The power distribution box is in the engine
compartment. It has high-current fuses
that protect the vehicle's main electrical
systems from overloads.
If you disconnect and reconnect the
battery, you will need to reset some
features. See Changing the 12V Battery
(page 254).
E173618
97
98
77
96
95
94
93 92 91 90 89
88
66
44
78
56
39
26
18 1617
3 12456789
192021222324
2728293031
40414243
55
575859606162636465
798081828384858687
67
45
32
10111213
333435
464748495051
6869707172
74
73
76
75
53
37 36
54
38
25
15
14
52
Protected componentsFuse amp ratingFuse or relay number
Fan relay 2.
40A
**
1
Fan relay 1.
40A
**
2
Trailer brake control module.
30A
**
3
Wipers.
30A
**
4
Washer pump.
Anti-lock brake system pump.
50A
**
5
233
Flex (), enUSA, First Printing
Fuses
