Ford Flex 2018 - Page 240

Protected ComponentsFuse Amp RatingFuse or Relay
Number
Front park lamps.
10A
2
48
Not used.-49
Heated mirrors.
10A
2
50
Not used.-51
Not used.-52
Trailer tow left-hand stop/turn lamps relay.Relay53
Not used.-54
Wiper relay.Relay55
Fuel injectors.
30A
2
56
Fuel pump relay.
Left-hand high intensity discharge head-
lamp.
20A
2
57
Alternator sensor.
10A
2
58
Brake on/off switch.
10A
2
59
Trailer tow back-up lamps.
10A
2
60
Not used.-61
A/C clutch relay.
10A
2
62
Trailer tow stop/turn lamps.
15A
2
63
Rear wipers.
15A
2
64
Not used.-65
Powertrain control module – vehicle power
relay.
Relay66
Vehicle power #2 – oxygen sensor heater.
20A
2
67
Mass airflow sensor.
Variable camshaft timing solenoid valve.
Canister vent solenoid.
Canister purge solenoid.
237
Flex (TP3) , enUSA, Edition date: 201801, Second Printing
Fuses
