Protected ComponentsFuse Amp RatingFuse or Relay
Number
Vehicle power #4 (ignition coils).
20A
2
68
Vehicle power 1 (powertrain control
module).
20A
2
69
Vehicle power #3 (coil) – A/C clutch relay.
15A
2
70
Fan control relay coils 1-3.
Variable air conditioning compressor.
Auxiliary transmission warmup.
Turbo charge waste-gate control.
Electronic compressor bypass valve.
All-wheel drive module.
Positive crankcase ventilation heater.
Not used.-71
Not used.-72
Not used.-73
Not used.-74
Not used.-75
Not used.-76
Trailer tow park lamps relay.Relay77
Right high-intensity discharge headlamp.
20A
2
78
Not used.-79
Not used.-80
Not used.-81
Rear washer.
15A
2
82
Not used.-83
Trailer tow park lamps.
20A
2
84
Not used.-85
Powertrain control module.
5A
2
86
Keep alive power and relay.
Powertrain control module relay.
238
Flex (TP3) , enUSA, Edition date: 201801, Second Printing
