Ford Focus - Instrument Cluster

GAUGES
A. Information display. See Information Displays for more information.
B. Speedometer
C. Engine coolant temperature gauge
D. Fuel gauge
E. Tachometer
Engine coolant temperature gauge
Shows the temperature of the engine coolant. At normal operating
temperature, the needle will remain in the center section. If the needle
enters the red section, the engine is overheating. Stop the engine, switch
the ignition off and determine the cause once the engine has cooled
down.
Note: Do not restart the engine until the cause of overheating has been
resolved.
WARNING: Never remove the coolant reservoir cap while the
engine is running or hot.
0
20
40
60
80
10 0
12 0
14 0
11 0
10
13 0
15 0
10 0
12 0
14 0
16 0
18 0
0
20
40
30
60
80
200
220
240
50
70
90
102 Instrument Cluster
