Fuse/Relay
Number
Fuse Amp
Rating
Protected Components
F30 — Not used
F31 — Not used
F32 10A* Exhaust gas recovery valve, Swirl
control valves, Heated oxygen sensors
F33 15A* Ignition coils
F34 10A* Injectors
F35 5A* Active grill shutter
F36 10A* Engine control module
F37 — Not used
F38 15A* Engine control module/Transmission
control module 15 feed
F39 5A* Headlamp control module (Focus ST)
F40 5A* Electronic power assist steering 15
feed
F41 20A* Body control module 15 feed
F42 15A* Rear Wiper
F43 15A* HID headlamp leveling (Focus ST)
F44 — Not used
F45 — Not used
F46 25A* Power windows front (without door
control unit)
F47 7.5A* Heated mirror (without door control
unit)
F48 5A* Power exterior mirror (without door
control unit)
R1 — Not used
R2 Micro relay Horn
R3 — Not used
R4 — Not used
R5 Micro relay Rear wiper
R6 — Not used
R7 — Not used
Fuses 239
2013 Focus (foc)
Owners Guide gf, 1st Printing
USA (fus)
