Circuits switchedRelay

Engine control module.R14

Heated rear window.R15

Ignition.R16

Passenger Compartment Fuse Box

178

Kuga (CBS) Vehicles Built From: 10-03-2014, Vehicles Built Up To: 31-12-2014, CG3585en enGBR, Edition date: 02/2014, None

Fuses
