Circuits protectedFuse ratingFuse
Hands-free liftgate actuation module.5AF1
Keyless vehicle module.10AF2
Keyless vehicle door handles.5AF3
Front left door control unit.25AF4
Front right door control unit.25AF5
Rear left door control unit.25AF6
Rear right door control unit.25AF7
Not used.-F8
Driver seat motor.25AF9
Not used.-F10
Rear ignition relay coil feed.5AF11
Climate control - vehicles with start-stop.10AF12
Instrument cluster - vehicles with start-stop.5AF13
Information and entertainment display.7.5AF14
SYNC module.
Global positioning system module - vehicles with
start-stop.
Audio unit - vehicles with start-stop.15AF15
Not used.-F16
Not used.-F17
Not used.-F18
Not used.-F19
Not used.-F20
Not used.-F21
Not used.-F22
Not used.-F23
AC/DC auxiliary power points.30AF24
Rear auxiliary power points.20AF24
