Antenna PositionsMaximum output power Watt (Peak
RMS)
Frequency Band
MHz
250 W220 - 225
250 W380 – 512
210 W806 – 870
210 W1200 – 1400
210 W1710 – 1885
210 W1885 – 2025
Note: After the installation of RF
transmitters, check for disturbances from
and to all electrical equipment in the
vehicle, both in the standby and transmit
modes.
Check all electrical equipment:
• with the ignition ON
• with the engine running
• during a road test at various speeds.
Check that electromagnetic fields
generated inside the vehicle cabin by the
transmitter installed do not exceed
applicable human exposure requirements.
TYPE APPROVALS
RF Certification Logos
Brazil
460
Ranger (TKE) Vehicles Built From: 02-05-2016 Vehicles Built Up To: 04-09-2016, EB3B-19G219-AKC enGBR, First Printing
Appendices
