Note: Secure luggage or cargo placed on
the load rest with the load rest stoppers.
TAILGATE
WARNINGS
Do not exceed the maximum
permissible tailgate load of 220 kg.
Vehicles fitted with a tow bar or rear
bumper should not have the tailgate
lowered without the support cables
in place.
Make sure that you keep a firm grip
of the tailgate to prevent it from
dropping down.
Lowering the Tailgate
WARNINGS
Do not lower the tailgate if a load
bed extension is fitted.
Maximum permissible load for a
tailgate with load bed extension is
50 kg.
1. Raise the tailgate slightly.
2. Pull the support cable rearwards.
3. Release the support cable from
tailgate.
4. Repeat steps 1 to 3 to pull out the
support cable on the other side.
Note: Lower the tailgate for better ingress
or egress of the loads.
170
Ranger (), EB3B-19G219-ZAB enAUS
Load Carrying
