3. Carefully prise out the lamp.
4
5
6
E134136
4. Disconnect the electrical connector.
5. Remove the bulb holder by pulling it
straight out.
6. Remove the bulb.
BULB SPECIFICATION CHART
Power ( Watts)SpecificationBulb
55H7Headlamp low beam.
+
55H11
Headlamp low beam.
++
55H15Headlamp high beam.
*
60HB3
Headlamp high beam.
**
15H15Daytime running lamps.
5W5WFront position lamp.
35H8Front fog lamp.
21P21WFront direction indicator.
-
1
Side direction indicator.
21WY21WRear direction indicator.
5W5WRear position lamp.
21/5W21/5WRear position/Stop lamp.
5W5WCentral high mounted brake
lamp.
245
Ranger (), EB3B-19G219-ZAB enAUS
Maintenance
