Ford TRANSIT COURIER User Manual

Removing the Cargo Net
E173028
1. Release the straps.
2. Remove the net from the luggage
anchor points.
3. Remove the upper bars.
INSTALLING AND REMOVING
THE REAR CARGO LUGGAGE
COVER
WARNING: Do not place objects
on the luggage cover. Failure to follow
this instruction could result in personal
injury or death in the event of a sudden
stop or crash.
Removing the Cover
E269210
1. Remove the luggage cover cords.
E291498
2. Lift the luggage cover to unclip and
rotate it by 180 degrees.
126
Tourneo Courier/Transit Courier (C4A) Vehicles Built From: 16-09-2021, CG3822en enGBR, Edition date: 202106, First-Printing
Rear Cargo Area
