Protected ComponentFuse RatingFuse Location
Dosing control unit.20 AF47
Dosing control unit.20 AF48
Dosing control unit.15 AF49
Protected ComponentRelay Number
Ignition.R1
Cigar lighter socket.R2
Front auxiliary power points.
Central locking system.R3
Heated exterior mirrors.R4
Selective catalytic reduction system.R5
Not used.R6
Not used.R7
Rear auxiliary power points.R8
Heated windshield.R9
Not used.R10
Windshield washer pump.R11
Windshield washer pump.R12
CHANGING A FUSE
Fuses
WARNING: Always replace a fuse
with one that has the specified
amperage rating. Using a fuse with a
higher amperage rating can cause severe
wire damage and could start a fire.
146
Tourneo Courier/Transit Courier (C4A) Vehicles Built From: 16-09-2021, CG3822en enGBR, Edition date: 202106, First-Printing
