Installation
1. Install the pump assembly and main control valve body onto the pump shaft.
2. Rotate the pump assembly and main control valve body to connect the manual valve link with the manual valve.
3. CAUTION: Do not use the bolts to draw pump assembly and main control valve body onto the chain cover case. Component damage may occur.
Using the Valve Body Aligner, install the pump assembly and main control valve body. Install the retaining bolt.
4. Install the transaxle wire harness and retaining clip into the separator plate.
5. Connect the electrical connectors.
6. NOTE: The transaxle side cover gasket is reusable if not torn or ripped.
Remove the gasket. Clean and inspect the gasket, reinstall into the pan.
