24
Installation and Initial assembly (508FS only)
Cooling fan option (continuation)
7
8
9
10
11
12
Position the fan unit on the crossmember.
Insert the mounting screws.
Fit the Fixing nut to the screw & tighten.
& Insert the IEC connector into the receptacle
located on the electrical box.
Secure the cable with the fixings supplied.
7
8
9
10 11
12
