18
P/N YRD604-KD-BLE-0047 Rev A
If deadbolt latch does not lock or unlock with the key (from the outside) or the
thumbturn (from the inside):
• Ensure that the deadbolt latch is centered in the face bore hole;
• Ensure that the tailpiece is positioned horizontally and inserted through
deadbolt latch slot (step 3, point 3) into the thumbturn slot (step 6, point 2).
Smooth deadbolt latch operation will enhance your battery life.
7
Test Thumbturn and Key
