Foscam FI9905B - Page 75

71
Infrared mode
Automatic or manual
IR range
With 1 Infrared Lamp Array, IR LEDs for IR range up to
20m / 66ft
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE 802.11b / g / n
Data Rate
IEEE802.11b: 11Mbps (Max.);
IEEE802.11g: 54Mbps (Max.);
IEEE802.11n: 150Mbps (Max.).
Frequency bands
2412-2472MHz
Maximum power
18dBm
Wireless Security
WEP, WPA, WPA2
Remote Access
P2P
Network Protocol
IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCPRTSP,
ONVIF
System
Requirements
Operating System
Microsoft Windows 2000/XP, Vista 7, 8;
Mac OS
Browser
Microsoft IE8 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari.
Other Features
Motion Detection
Alarm via E-mail, upload alarm snapshot to FTP
User Accounts
Three levels user role
Firewall
Supports IP Filtering
Reset
Reset button is available
Power
Power Supply
DC 12V / 1.0A
Power Consumption
4.2 Watts (Max.)
Physical
Dimension (L * W * H)
153mm * 92mm * 86mm / 6.0in * 3.6in * 3.4in
Net Weight
380g / 0.8lb
Environment
Operating
Temperature
-20ºC ~ 60ºC (-4ºF ~ 140ºF)
Operating Humidity
10% ~ 80% non-condensing
Storage Temperature
-20ºC ~ 60ºC (-4ºF ~ 140ºF)
Storage Humidity
0% ~ 90% non-condensing
Certification
IC, CE, FCC, RoHS
ITEMS
FI9803EP
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
1280 * 720 (1.0 Megapixels)
Min. Illumination
0 Lux (with IR Illuminator)
Lens
Lens Type
Glass Lens
focal length
f: 4mm (option 2.8mm,6mm,8mm)
Aperture
F1.2
Angle of View
Horizontal:70º
