Foscam FI9905B - Page 78

74
Display Resolution
1280 * 720 (1.0 Megapixels)
Min. Illumination
0 Lux (with IR Illuminator)
Lens
Lens Type
Glass Lens
focal length
f:2.8mm
Aperture
F1.2
Angle of View
70º
Video
Image Compression
H.264
Image Frame Rate
30fps (60Hz), 25fps (50Hz), downward adjustable
Resolution
720P (1280 * 720), VGA (640 * 480), QVGA (320 * 240)
Stream
dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image
flip and mirror
Infrared mode
Automatic or manual
IR range
12pcs IR-LEDs, IR LEDs for IR range up to 20m / 66ft
Audio
Input / Output
External RCA interface for two-way audio
Audio Compression
PCM / G.726
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE802.11b / g / n
Data Rate
IEEE802.11b: 11Mbps (Max.);
IEEE802.11g: 54Mbps (Max.);
IEEE802.11n: 150Mbps (Max.).
Frequency bands
2412-2472MHz
Maximum power
18dBm
Wireless Security
WEP, WPA, WPA2
Network Protocol
IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCPRTSP,
ONVIF
System
Requirements
Operating System
Microsoft Windows 2000/XP, Vista 7;
Mac OS
iOS, Android
Browser
Microsoft IE6 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari.
Other Features
Motion Detection
Alarm via E-mail, upload alarm snapshot to FTP
Privacy Block
Set privacy area manually
User Accounts
Three levels user role
Firewall
Supports IP Filtering
Reset
Reset button is available
Power
Power Supply
DC 12V / 1.0A
Power Consumption
5.2 Watts (Max.)
Physical
Dimension (L * W * H)
132mm * 72mm * 80mm / 5.2in * 2.8in * 3.1in
Net Weight
870g / 1.9lb
Environment
Operating
-20ºC~ 60ºC (-4ºF ~ 140ºF)
