5
[INPUT SEL] switch
Used to select the type of analog signal that the
digital signal is transformed into.
Choose between left and right (R+L), left only (L),
and right only (R).
[AC IN] terminal
Used to connect to a power outlet using the
supplied power cord.
[INPUT BALANCED] terminal
XLR balanced analog input terminal.
6301NX uses a transformer type balanced system,
and 6301NE uses an electronic type balanced
system.
6301NX/NE
(The unit pictured above is 6301NX.)
6301NB
