Fostex 6301ND - Troubleshooting; No Sound Problem; Specifications; Technical Specifications

7
Troubleshooting
Problem Solutions
There is no sound.
• Check the connection. (

page 4, page 5, page 6)
• Check the set volume of each device.
Specifications
6301ND 6301NX 6301NE 6301NB
Type Sealed powered speaker system
Speaker 100 mm cone-shaped, full-range speaker × 1
Frequency band 70 Hz to 15 kHz
Output sound
pressure level
85 dB/W (1 m)
Maximum output
sound pressure level
98 dB
Rated output 20 W
T. H. D. 0.05% (at 1 kHz 1 W output)
Input terminal
Analog unbalanced/φ6.3 mm (1/4") TS phone
Digital XLR-3-31 type
IEC60958 (AES/EBU)
sampling frequency
44.1 kHz to 96 kHz
Analog balanced
XLR-3-31 type HOT No. 2/
transformer type
Analog balanced
XLR-3-31 type HOT No. 2/
electronic type
—
Output terminal
(THRU)
Digital XLR-3-32 type —
Input impedance Analog input (balanced/unbalanced) 10 kΩ or more
Input sensitivity
Analog (unbalanced):
-14 dBV (0.2 Vrms)
Digital: -12 dBFS
Analog (unbalanced): -14 dBV (0.2 Vrms)
Analog (balanced): +4 dBu (1.2 Vrms)
Analog (unbalanced):
-14 dBV (0.2 Vrms)
Residual noise − 65 dBV − 70 dBV
Enclosure material Aluminum die-casting
Power
consumption
10 W
External
dimensions (mm)
120 (W) × 189 (H) × 120 (D)
Weight Approx. 2.3 kg
Length of the
power cord
Approx. 2 m
