FOTILE EMS6008 - Assembly Height; Installation

- 12 - - 13 -
Installation
Assembly Height
The marked dimensions are for reference only (unit: mm)
Installation diagram of Exhaust Type Range Hood
360
280
600
243
113
Φ
180
The center
line
The hole size of the ceiling or cupboard top plate The hole size of the cabinet bottom plate
★ 271
★ 522
Cushion
36
75
491
600-650
595
EMS6008 Installation diagram (
★
indicating the distance to the wall)
36
75
505~830
600~650
595
★ 275
★ 522
Cushion
EMS6008-C Installation diagram (
★
indicating the distance to the wall)
★ 275
★ 522
36
75
660~830
595
600~650
Cushion
Installation diagram of Inner Circulating Type Range Hood
(
★
indicating the distance to the wall)
