UNPACKING AND CLEANING
Unpack your saw carefully, taking care with the loose parts.
Note : if any parts are damaged or missing, do not connect the machine to the power and do not switch it on until the
missing/damaged parts are replaced.
Do not throw away the cardboard box until you are sure the machine is working correctly.
The table saw is supplied partially assembled, with the following parts :
 Table top and body fitted with carbide-tipped saw blade
 Rip fence
 Rip fence slide and lock
 Mitre fence
 Blade guard
 Riving knife
 Push stick
 Rear extension
 Side extension x 2
 Stand legs with fitted rubber feet x 4
 Short upper braces x 2
 Long upper braces x 2
 Middle braces x 4
 Rear extension supports x 2
 Wheel axle
 Wheels x 2
 Wheel brackets x 2
 Wheel handles each with star washer and dome nut x 2
 Blade change spanners x 2
 Hex key
 Carriage bolts with plain washer, spring washer and nut (stand assembly) x 32
 M6 x 12mm screw with 2 plain washers, spring washer and nut x 4
 Circlip (wheels to axle) x 2
 Side extension lock (side extensions) x 4
 M6 x 12mm screw with plain washer and spring washer (rear extension to table top) x 3
 M6 x 16mm screw with 2 plain washers, spring washer and nut (wheel bracket to leg) x 4
 Black cross head screw with 2 plain washers, spring washer and nut (rear extension supports to rear extenstion)
x 2
 Black cross head screw with plain washer and spring washer (rear extension supports to table body) x 2
 Push stick clamps and 4 x 3.2mm x 10mm screws (packed separately) x 2
 Set screw and 3mm hex key (side extensions) x 4
 Instructions manual
