9
AIR SPRING VOLUME SPACERS
Changing volume spacers in FOX FLOAT forks is an easy internal adjustment that allows you to
change the amount of mid stroke and bottom out resistance. If you have set your sag correctly
and are using full travel (bottoming out) too easily, then you could install one or more spacers
to increase bottom out resistance. If you are not using full travel, then you could remove one or
more spacers to decrease bottom out resistance.
1. Remove the air cap.
2. Release all air pressure from the fork by depressing the Schrader valve.
3. Carefully unthread the topcap from the fork with a 6-point chamfer-less 26 mm socket
(for 36 Forks, use a 6-point chamfer-less 32 mm socket).
4. Pull up to remove the topcap assembly from the fork crown.
5. Slide the air volume spacer or spacers horizontally to install or remove them from the topcap.
6. Reinstall the topcap assembly into the fork crown and tighten to 24.8 Nm (220 in-lb) with
a 6-point chamfer-less 26 mm socket (for 36 Forks, use a 6-point chamfer-less
32 mm socket).
7. Add air pressure to your desired setting using a FOX high-pressure pump. Set the sag
according to instructions online at www.ridefox.com.
WARNING
FOX forks may contain high air pressures. Release ALL air pressure from the main air
chamber before disassembly. Failure to do so may result in parts or fluids ejecting
from the fork, which can cause SEVERE INJURY OR DEATH.
WARNING
Do not exceed the maximum number of volume spacers for your fork. This can
damage your fork. Find volume spacer information online at www.ridefox.com.
