Fox MARS - Equipment Settings Before Operation; Pre-Operation Adjustments

GB
INSTRUCTION MANUAL
Fig. 4
EQUIPMENT SETTINGS BEFORE OPERATION
1. Adjustment of the helmet angle up to 28 degrees using the handles (fig. 5)
2. Equipment height adjustment: hold down the equipment handrail slightly, pull or press it and
then set the required height.
3. Equipment height adjustment: hold down the equipment handrail slightly, pull or press it and
then set the required height.
Fig. 5
Fig. 6
Helmet knob
Rotary cover
The added water container cover
Sealing ring on the water inlet
Max water level
Guide rail
Sealing ring on the steam outlet
Return water container
f) Arrange the container holder in the horizontal position and close the equipment cover.
