Fox PERFORMANCE 2.5 Series - Shock Diagram

605-01-378 2
SHOCK DIAGRAM
2
2
7
5
5
4
4
3
3
6 6
8 8
1
PART NO. NAME PART NO. NAME
1 Eyelet 5 Preload ring
2 Shock body 6 Shaft
3 Bearing cap 7 Bar-pin bolt
4 Molded spring seat 8 Center nut
FRONT COIL-OVER REAR COIL-OVER
