FoxAlien Reizer - How to Assemble the Machine

1
How to Assemble the Machine
-3-
Y-axis Aluminum Profile (Left) Button Head Socket Bolt M5*10 T-nut M5
Y-L AXIS
10
2
12
No need to completely
tighten the screw. We’ll
need it to install the other
profiles later.
2x
2x
No need to completely
tighten the screw. We’ll
need it to install the other
profiles later.
1x
